Taft-Peirce Sine Blocks

Taft-Peirce sine plates let you set and check precise angles by stacking gage blocks under the hinged top, a proven method for grinding, machining, and inspecting angled work. Machinists and QC inspectors use them with a sine bar calculator to dial in exact angles for setup and squareness checking.

Available in inch and metric sizes from Suburban Tool, these Taft-Peirce sine plates are Made in USA and precision ground. Learning how to use a sine plate is straightforward once you understand the gage block stack.

  • Precision sine plates for setting and checking angles
  • Inch and metric sizes available
  • For angle grinding, machining, and inspection
  • Premium Taft-Peirce precision, Made in USA

Prices in US$. Click a model number for photos, details and certification options.

Taft-Peirce Sine Blocks

Swipe the table sideways for all specs. Price and Add to cart stay in view.

ModelLengthWidthHeightTapped HolesCenter DistanceSquare & ParallelWeightPrice
9118-56-13/16"2-1/8"2-1/8"10-325" ±0.0002"0.0001"8 lb$2,032.80
9118-1011-5/8"4"2-5/8"10-3210" ±0.0003"0.0002"21 lb$4,824.75
9118-5M136mm50mm51.6mmM4100mm ±0.0051mm0.0026mm7 lb$2,132.55
9118-10M292mm101.6mm66.7mmM5250mm ±0.0076mm0.0051mm21 lb$5,514.60

Videos

How to Set a Sine Plate or Sine Bar
Sine Plate Comparison - Suburban vs EX-CELL-O vs Taft-Peirce
Free Online Calculator for setting a Sine Plate or Sine Bar from Suburban Tool
