The 9118-5M Taft-Peirce Sine Plate measures 50mm x 136mm and is made by Suburban Tool for accurate angle work in compact setups. With a stack of gage blocks and the sine principle, this small metric plate lets toolmakers and inspectors set precise angles for surface grinding, layout, and checking of fine precision parts.

  • Compact 50mm x 136mm surface for small metric work
  • Sets exact angles from gage blocks using the sine method
  • Rigid Taft-Peirce construction for dependable accuracy
  • Great for surface grinding, layout, and QC inspection
  • Precision angle tooling from Suburban Tool
  • Made in the USA by Suburban Tool

Taft-Peirce

Taft-Peirce Sine Block, 50 × 136 mm (9118-5M)

SKU 9118-5M
$2,132.55

The 9118-5M Taft-Peirce Sine Plate measures 50mm x 136mm and is made by Suburban Tool for accurate angle work in compact setups. With a stack of gage blocks and the sine principle, this small metric plate lets toolmakers and inspectors set precise angles for surface grinding, layout, and checking of fine precision parts.

  • Compact 50mm x 136mm surface for small metric work
  • Sets exact angles from gage blocks using the sine method
  • Rigid Taft-Peirce construction for dependable accuracy
  • Great for surface grinding, layout, and QC inspection
  • Precision angle tooling from Suburban Tool
  • Made in the USA by Suburban Tool

Specifications

Model 9118-5M
Length 136mm
Width 50mm
Height 51.6mm
Tapped Holes M4
Center Distance 100mm ±0.0051mm
Square & Parallel 0.0026mm
Weight 7 lb
$2,132.55

Allow up to 2 days for order processing. Items not in stock are made to order in Auburn Hills, Michigan; we email you the expected date, and they ship separately with their own shipping charge.
