The Suburban Tool 9131-M is a matched pair of Taft-Peirce V-Blocks, each 2-3/4" x 2-3/8" x 1-7/8", supplied as a metric set for balanced two-point support of larger cylindrical workpieces.

Working the blocks together lets you bracket longer, heavier shafts on both ends for parallel, repeatable setups.

  • Matched pair spans long round stock across two locating points
  • Generous 2-3/4" blocks for drilling, milling, and layout
  • Ground faces seat squarely on grinders and inspection plates
  • Metric-dimensioned set for shops working in millimeters
  • Taft-Peirce matched precision workholding from Suburban Tool
  • Made in the USA by Suburban Tool
  • Available as a single block or in pairs matched within 0.0003" and numbered for identification.
  • Clamps do not interfere, when vee blocks are used on sides or ends, and may be swung aside or removed entirely.
  • Pairs are furnished in a wooden storage case.
  • Each v-block has a 23/32" hole drilled in the center of the vee -- useful for providing clearance for drilling and boring operations.
  • Base ledge has four 5/16-18 tapped holes for convenient clamping to angle irons or face plates.
  • Each block is provided with two clamps and four clamping screws.

Suburban Tool Inc.

Taft-Peirce V-Block, 2-3/4" × 2-3/8" × 1-7/8", Pair (Metric) (9131-M)

SKU 9131-M
$2,525.25

The Suburban Tool 9131-M is a matched pair of Taft-Peirce V-Blocks, each 2-3/4" x 2-3/8" x 1-7/8", supplied as a metric set for balanced two-point support of larger cylindrical workpieces.

Working the blocks together lets you bracket longer, heavier shafts on both ends for parallel, repeatable setups.

  • Matched pair spans long round stock across two locating points
  • Generous 2-3/4" blocks for drilling, milling, and layout
  • Ground faces seat squarely on grinders and inspection plates
  • Metric-dimensioned set for shops working in millimeters
  • Taft-Peirce matched precision workholding from Suburban Tool
  • Made in the USA by Suburban Tool
  • Available as a single block or in pairs matched within 0.0003" and numbered for identification.
  • Clamps do not interfere, when vee blocks are used on sides or ends, and may be swung aside or removed entirely.
  • Pairs are furnished in a wooden storage case.
  • Each v-block has a 23/32" hole drilled in the center of the vee -- useful for providing clearance for drilling and boring operations.
  • Base ledge has four 5/16-18 tapped holes for convenient clamping to angle irons or face plates.
  • Each block is provided with two clamps and four clamping screws.

Specifications

Model 9131-M
Single or Pair Pair
Length 2-3/4"
Width 2-3/8"
Height 1-7/8"
Vee Capacity 1-1/2"
Vee Central, Square & Parallel 0.0003"
Sides Square & Parallel 0.0002"
Weight 7 lb
$2,525.25
