The Suburban Tool B-246-H23-M is a precision block set measuring 2" x 4" x 6", supplied as a matched pair in hardened steel and ground on all six sides. Its 23 holes include 3/8-16 tapped holes with matching clearance, so machinists can screw-mount the blocks for a wide range of precision set-ups.
Furnished in a fitted wooden box, this larger matched pair from Suburban Tool is a rigid, dependable reference for layout, setup, workholding and inspection in the toolroom.
- Matched pair of hardened steel blocks for balanced, repeatable work
- Ground on all six sides for true, square and parallel faces
- 23 holes with 3/8-16 tapped holes and matching clearance
- Screw-mount for angle plates and other precision fixtures
- Supplied in a fitted wooden storage box
- Made in the USA by Suburban Tool
Available with No Certification, Short Form, or Long Form Certification.
The Suburban Tool B-246-H23-M is a precision block set measuring 2" x 4" x 6", supplied as a matched pair in hardened steel and ground on all six sides. Its 23 holes include 3/8-16 tapped holes with matching clearance, so machinists can screw-mount the blocks for a wide range of precision set-ups.
Furnished in a fitted wooden box, this larger matched pair from Suburban Tool is a rigid, dependable reference for layout, setup, workholding and inspection in the toolroom.
- Matched pair of hardened steel blocks for balanced, repeatable work
- Ground on all six sides for true, square and parallel faces
- 23 holes with 3/8-16 tapped holes and matching clearance
- Screw-mount for angle plates and other precision fixtures
- Supplied in a fitted wooden storage box
- Made in the USA by Suburban Tool
Available with No Certification, Short Form, or Long Form Certification.
Specifications
| Model | B-246-H23-M |
|---|---|
| Single or Pair | Pair |
| Holes | 23 |
| Square | 0.0001"/1" |
| Flat & Parallel | 0.0003" |
| Size (Inches) | 2" x 4" x 6" +0.0001"/+0.0004" |
| Weight | 24 lb |
- Regular price
- $1,065.75
