- Fagor NVP-200 QC 3-axis digital readout* with:
- Geometric functions.
- Easy calculation of distance, angle, intersection, radius, diameter, part skew, etc.
- Output to printer or PC.
- Display reads to 0.0001".
- 1 micron glass scales.
- Fiber optic edge detection.
- 360° digital protractor.
- Surface illumination through duplex fiber optics.
- High capacity 4" x 8" travel stage with 4-1/2" x 19" work surface.
- Ball way construction handles loads to 100lbs.
- Two long-life tungsten-halogen light sources.
- Extra bright surface illumination through duplex fiber optics.
- Individual switches select profile, surface or combination surface-profile illumination modes.
- Heavy-duty monorail type, welded steel frame.
- Rotary frosted glass screen with 90° crosslines and 360° protractor markings.
- Screen-mounted overlay chart clips.
- 10 power lens system.
- Weighs 229 lbs.
- Measures 48-1/2" long x 22-1/4" wide x 34" high.
|
